产品参数

旋流器、规格、处理量

                                                              规格和参数

规格                 直径                   进料压力                   处理能力                  分离粒度

                    （mm）                  (MPa)                       ( m³/h)                       (μm)

FX840             840                    0.04-0.15                  500-900                    74-350

FX710             710                    0.04-0.15                 400-550                     74-250

FX660             660                    0.04-0.15                  260-450                    74-220

FX610             610                    0.04-0.15                  200-300                    74-200

FX500             500                    0.04-0.2                    140-240                    74-200

FX400             400                    0.06-0.2                    100-170                    74-150

FX350             350                    0.06-0.2                     70-160                     50-150

FX300             300                    0.06-0.2                     45-90                       50-150

FX250             250                    0.06-0.3                     40-80                       40-100

FX200             200                    0.06-0.3                     25-40                        40-100

FX150             150                   0.08-0.3                      14-35                        20-74

FX125             125                    0.1-0.3                        8-20                          25-50

FX100             100                    0.1-0.3                        8-20                         20-50

FX75                75                     0.1-0.4                        5-10                         10-40

FX50                50                     0.1-0.4                        2-5                            5-40

FX25                25                     0.1-0.6                        0.3-1                          5-20

FX10                10                     0.1-0.6                        0.05-0.1                     1-5

   邢台久泰筛分设备有限公司，是一家***生产聚氨酯筛板（条缝 方孔 圆孔等），水利.重介.旋流器的***生产商，也是国内***的筛分设备品牌厂家。公司拥有研究、生产、 试验一体化设备，产品广泛用于尾矿干排、矿浆浓缩脱水 、脱泥、微细粒物料分级、尾矿充填、以及泥浆脱水等。公司为了与客户创造良好的经济效益，我公司承接各种非标设计。公司以过硬的产品质量和良好的企业信誉与国内数家***单位建立了长期合作关系。公司本着“以质量求生存，以信誉求发展”的原则，欢迎各界人士前来参观考察洽谈业务。全国服务热线：.
